Techna
Lampada ultra-thin di nuova generazione con corpo in alluminio, adatta ad applicazioni personalizzate e montaggio a plafone, pendente, a parete.
Eficiencia energética
| Source efficiency | 192 lm / W @ 160mA 4000 ° K |
| Net effective efficiency | 136 ~ 145 lm / W |
| LED power supply current | <100mA |
| Optical group | MTPL |
| Color temperature | 3000 ° K - 4000 ° K |
| Color Rendering Index | > 80 -> 90 |
| Photobiological risk | Exempt Group |
| LED diode life | > 100,000 hh L90B05 |
| Color | Satin black - Satin white (other colors on request) |
| Gasket | Pure silicone |
| Guarantee | 10 years |
Datos técnicos
| power supply | Multiple on single chip, integrated into the LED board |
| Supply | 230Vac ± 10% 50/60 Hz |
| Insulation class | Class II |
| PF | > 0.98 |
| Degree of protection | IP65 |
| Resistance index | IK09 |
| Operating Temp. ° C | -20 ° / + 40 ° C |
| Power connection | 1.5m pre-wired cable (other sizes on request) |
| Apparatus assembly | Ceiling, suspension, bracket, joint |
| UGR | <19 |
| Body material | Powder coated aluminum |
| Screen | Microprismatic in a single body |
| TLC ready | Opt. |
| Card protection | Ultra-fast fuse, MOV |
| SPD protection |
PLANTILLA:
TCHB1
DIMENSIONES:
795 x 102 x 36 mm
PESO:
1,5 kg
PLANTILLA:
TCHB2
DIMENSIONES:
795 x 102 x 36 mm
PESO:
1,5 kg
PLANTILLA:
TCHC2
DIMENSIONES:
1245 x 65 x 36 mm
PESO:
2,5 kg
PLANTILLA:
TCHC4
DIMENSIONES:
1245 x 65 x 36 mm
PESO:
2,5 kg
PLANTILLA:
TCHD2
DIMENSIONES:
1545 x 65 x 36 mm
PESO:
3,1 kg
PLANTILLA:
TCHD4
DIMENSIONES:
1545 x 65 x 36 mm
PESO:
3,1 kg
